Wednesday, December 21, 2011

C/C++ alternative preprocessing tokens

C++ has a set of alternative preprocessing tokens:
2.5/1
 and_eq &=
 and &&
 xor_eq ^=
 or ||

[..]


It turned out that C has them as well:
7.9
The header iso646.h defines the following eleven macros (on the left) that expand to
the corresponding tokens (on the right):

cat 4.6.3/include/iso646.h

#ifndef _ISO646_H
#define _ISO646_H

#ifndef __cplusplus
#define and     &&
#define and_eq  &=
#define bitand  &
#define bitor   |
#define compl   ~
#define not     !
#define not_eq  !=
#define or      ||
#define or_eq   |=
#define xor     ^
#define xor_eq  ^=
#endif

#endif


Wednesday, December 14, 2011

rq_of_rt_rq...


 kernel/sched_rt.c
 [..]
 113 static void dec_rt_migration(struct sched_rt_entity *rt_se, struct rt_rq *rt_rq)
 114 {
 115         if (!rt_entity_is_task(rt_se))
 116                 return;
 117
 118         rt_rq = &rq_of_rt_rq(rt_rq)->rt;
 119
 120         rt_rq->rt_nr_total--;
 121         if (rt_se->nr_cpus_allowed > 1)
 122                 rt_rq->rt_nr_migratory--;
[..]

Try to read `rt_rq = &rq_of_rt_rq(rt_rq)->rt;' fluently :-)

Sunday, December 11, 2011

LinuxFr.org: Interview with Andrew Tanenbaum

Andrew Tanenbaum on Linux, GPL and stuff

LinuxFr.org : Do you think the Linux success is a proof he was right
or is it unrelated?

Andrew Tanenbaum : No, Linux "succeeded" because BSD was frozen out of
the market by AT&T at a crucial time. That's just dumb luck. Also, success
is relative. I run a political website that ordinary people read. On that
site statistics show that about 5% is Linux, 30% is Macintosh (which is BSD
inside) and the rest is Windows. These are ordinary people, not computer
geeks. I don't think of 5% as that big a success story.


Monday, November 28, 2011

2.373

Scott Aaronson writes:

For twenty years, the fastest known algorithm to multiply two n-by-n matrices, due to Coppersmith and Winograd, took a leisurely O(n2.376) steps.   Last year, though, buried deep in his PhD thesis where hardly anyone saw it, Andy Stothers discussed an improvement to O(n2.374) steps.  And today,  Virginia Vassilevska Williams of Berkeley and Stanford, released a breakthrough paper that improves the matrix-multiplication time to a lightning-fast O(n2.373) steps.

...The world will not be the same!

C++11 N2765: user-defined literals

C++11 will have tons of new features and concepts. One among them is
N2765: user-defined literals (scheduled for GCC 4.7). Quite possible I'm dumb
and ugly, but frankly, "user-defined literals" is something I've so many doubts
about. There're already lots of examples, though I haven't seen anything really
neat so far (only speaking for myself).


For example:

constexpr long double operator"" _degrees (long double d)
{
        return d * 0.0175;
}

long double pi = 180_degrees;


Or (link)

typedef std::map MyMap;
MyMap create_map()
{
    MyMap m;
    m["lol"] = 7;
    return m;
}

auto m = create_map();

int& operator "" m(const char *key, size_t length)
{
        return m[key];
}

int main(void)
{
    std::cout << "lol"m << std::endl;
    // 7
    "lol"m = 2;
    std::cout << "lol"m << std::endl;
    // 2
    return 0;
}



Or (link)

template struct __checkbits
{
    static const bool valid = false;
};

template struct __checkbits
{
    static const bool valid = (High == '0' || High == '1')
                   && __checkbits::valid;
};

template struct __checkbits
{
    static const bool valid = (High == '0' || High == '1');
};

template
  inline constexpr std::bitset
  operator"" _bits() noexcept
{
    static_assert(__checkbits::valid, "invalid digit in binary string");
    return std::bitset((char []){Bits..., '\0'});
}

int main()
{
  auto bits = 010101010101010101010101010101010101010101_bits;
  std::cout << bits << std::endl;
  std::cout << "size = " << bits.size() << std::endl;
  std::cout << "count = " << bits.count() << std::endl;
  std::cout << "value = " << bits.to_ullong() << std::endl;

  //  This triggers the static_assert at compile time.
  auto badbits = 21010101010101010101010101010101010101_bits;

  //  This throws at run time.
  std::bitset<64> badbits2("21010101010101010101010110101010101_bits");
}



-ss

Tuesday, November 22, 2011

GCC 4.7.0: transactional memory

Eventually GCC 4.7.0 will have transactional memory, which has been
merged several days ago. Draft of still-in-progress design document can
be found here.

In short, (atomic) transaction is something similar to this:

    __transaction_atomic { x++; }

Any operation performed within the __transaction_atomic block will be atomic and
isolated from other transactions, operations within __transaction {} either be visible to other threads in its entirety or not at all.

Quote from lwn
Details on the specific implementation are scarce; it appears that, in the current patch set,
transactions will be implemented using a global lock. GCC developers debated for a bit over
whether this code was ready for merging or not. In the end, though, the possibility of being
the first to support an interesting new feature seemed to win out. Current plans are to
release 4.7.0 sometime around next April.

Refer to gcc.gnu.org (or gcc 4.7 svn repository) for details.

Tuesday, November 15, 2011

Prettiness of git hooks

Haven't blogged for a while, so just to keep this blog alive, some easy reading.
Recently due to project needs we had to organize external .git repository mirror for
code drops. The below notes probably will not discover anything new to you, though
still may be interesting. Just in case.

Well, to start with, we have several developer's trees and one master tree (obviously
for merging, pushing and keeping stuff(tm)). We also have to perform regular code drops
(say, several times a week) with .git directory included. The usual solution could be
just to perform `clone, pull, pull,...' on the remote machine, which, however, didn't
work for us because of some company policies.

So I performed trivial scp of cloned master tree to the remote machine (which is possibly
not the best thing to do, but I didn't feel like doing all that git init, scp files,
git add, git commit with "Initial commit" message, etc.), and cleaned up .git/config.

For scp-ed repo we should perform:
git config --bool core.bare true
otherwise an attempt to push will make git suspicious that you may accidentally screw
things up:
remote: error: refusing to update checked out branch: refs/heads/master
remote: error: By default, updating the current branch in a non-bare repository
remote: error: is denied, because it will make the index and work tree inconsistent
remote: error: with what you pushed, and will require 'git reset --hard' to match
remote: error: the work tree to HEAD.
remote: error:
remote: error: You can set 'receive.denyCurrentBranch' configuration variable to
remote: error: 'ignore' or 'warn' in the remote repository to allow pushing into
remote: error: its current branch; however, this is not recommended unless you
remote: error: arranged to update its work tree to match what you pushed in some
remote: error: other way.
remote: error:
remote: error: To squelch this message and still keep the default behaviour, set
remote: error: 'receive.denyCurrentBranch' configuration variable to 'refuse'.


The thing is that on the remote side we have to create --tag each time we perform
a code drop. And this is kind of error prone because it's so easy just to forget
perform git tag..., git push --tags.

So I created an alias for tagging on the remote machine

.git/config
[alias]
        datetag = !git tag "project_name_"`date +%Y%m%d%H%M`


(or perhaps time zone aware one via `TZ='REGION/CITY' date +%Y%m%d%H%M`).


The next thing was tagging automation. Which was simply achieved by
git hooks (git book). There are lots of them (you can find examples within
.git/hooks/ directory). In order to enable hook, just remove .sample at the end
of file name.

The ideal candidate was:
post-receive
GIT_DIR/hooks/post-receive
This hook is invoked by 'git-receive-pack' on the remote repository, which happens when a
'git-push' is done on a local repository. It executes on the remote repository once after
all the refs have been updated.



With somewhat trivial implementation:
.git/hooks/post-receive
#!/bin/sh
#
# To enable this hook, rename this file to "post-update".

exec git datetag




Since hooks are shell scripts it's really almost up to you to decide
the level of `complexity' and `sophistication'.


On the local host I created addition 'remote' config
.git/config
[remote "drop"]
        url = git@remote_host_name:/project_repository_path


and set appropriate ssh IdentityFile for Host in ~/.ssh/config file.

So now I can perform
1) git push
for pushing to local master

2) git push drop
for pushing and tagging to the remote host


That's it, git is really awesome.

-ss

Sunday, October 23, 2011

Saturday, October 15, 2011

Bits of History

The C Family of Languages: Interview with Dennis Ritchie, Bjarne Stroustrup, and James Gosling

This article appeared in Java Report, 5(7), July 2000 and C++ Report, 12(7), July/August 2000.
VIa  gotw.ca

Thursday, October 13, 2011

Thank you Dennis

Dennis MacAlistair Ritchie
September 8, 1941 — October 8/9, 2011


" ... was an American computer scientist notable for developing C and
for having influence on other programming languages, as well as operating
systems such as Multics and Unix... "





Image and text via wikipedia

Thursday, October 6, 2011

R.I.P. Steve

 February 24, 1955 – October 5, 2011


image via wikipedia.org

Monday, October 3, 2011

Guess who's back

The restored kernel.org is back on line - partially. It holds the mainline tree, the stable tree, and linux-next; as of this writing, all hold their pre-shutdown contents. Expect those trees to be updated soon; other trees will slowly reappear as their developers obtain new credentials on the site. Services other than git and FTP (the wiki, mirrors, etc.) remain offline. (Note that there appears to be some residual weirdness around the site's SSL certificate, leading to "untrusted connection" warnings if you try to use HTTPS).
via lwn.net

Tuesday, September 27, 2011

kernel.org knockdown and 3.2 merge window

Stephen Rothwell wrote:
I have just done a quick check of the trees that are merged into
linux-next each day.  Of the 171 trees that represent work for the next
merge window, 89 only exist on kernel.org machines.  This means
(obviously) that I have not had updates to those 89 trees since the
kernel.org servers were taken down.

Sunday, September 25, 2011

kernel.org status update

The developers working on putting kernel.org back together have sent out a brief status update, mostly about the management of git trees. "This new infrastructure will no longer have shell access to the git repositories; instead we will be running git using the gitolite web glue. Gitolite uses ssh keys to push into it, so we will start sending out new ssh credentials to the active developers who had kernel.org accounts before." Git trees should go back online in the near future; everything else will take longer.

via lwn.net

Wednesday, September 21, 2011

insteadOf git.kernel.org

Surprisingly long maintenance downtime for kernel.org
(and especially git.kernel.org) gave me a chance to learn
git insteadOf trick. I already have replaced a couple of URLs,
for example:
[url "https://github.com/torvalds/linux.git"]
        insteadOf = git://git.kernel.org/pub/scm/linux/kernel/git/torvalds/linux-2.6.git


But the real power comes with something like this:

[url "git://readonly.mysuperproject.org"]
    insteadOf = "git://mysuperproject.org"
[url "ssh://gurusonly.mysuperproject.org"]
    pushInsteadOf = "git://mysuperproject.org"


Tuesday, September 13, 2011

C++0x extended friend syntax

While reading gcc 4.7 Changes, New Features, and Fixes list

[..]
- G++ now implements C++0x extended friend syntax:
    template
    class Q
    {
      static const int I = 2;
    public:
      friend W;
    };

    struct B
    {
      int ar[Q<B>::I];
    };
 [..]


Yeah, that's possibly cool to skip class key for friend declaration...
But wait... really...

int ar[Q<B>::I];

how is that klingon supposed to be readable in anyway?


int ar[Q<T,M>::I & 255 + X<B<C>>::I << 2];


Monday, September 12, 2011

Tuesday, August 30, 2011

Monday, August 15, 2011

Asking gcc for help

Useful trick to make "the hard stuff" easier (unless you're bright
in asm) is


gcc -c -g -Wa,-a,-ad  test.c > test.s

That will ask gcc to dump generated assembly with the corresponding C lines.
For example:

   1                            .file   "test.c"
   2                            .text
   3                    .Ltext0:
   4                            .local  pm_pipe
   5                            .comm   pm_pipe,8,4
   6                            .local  pm_notify_thread
   7                            .comm   pm_notify_thread,8,8
   8                            .section        .rodata
   9                    .LC0:
  10 0000 54485245              .string "THREAD\n"
  10      41440A00
  11                    .LC1:
  12 0008 74696D65              .string "timeout...\n"
  12      6F75742E
  12      2E2E0A00
  13                    .LC2:
[..]
  17                            .text
  19                    pm_notify:
  20                    .LFB0:
  21                            .file 1 "test.c"

[..]
  26:test.c        ****                 pfd[0].fd = pm_pipe[0];
  51                            .loc 1 26 0
  52 0046 8B050000              movl    pm_pipe(%rip), %eax
  52      0000
  53 004c 8945E0                movl    %eax, -32(%rbp)
  27:test.c        ****                 pfd[0].events = POLLIN;
  54                            .loc 1 27 0
  55 004f 66C745E4              movw    $1, -28(%rbp)
  55      0100
  28:test.c        ****
  29:test.c        ****                 ret = poll(pfd, 1, 5 * 1000);
  56                            .loc 1 29 0
  57 0055 488D45E0              leaq    -32(%rbp), %rax
  58 0059 BA881300              movl    $5000, %edx
  58      00
  59 005e BE010000              movl    $1, %esi
  59      00
  60 0063 4889C7                movq    %rax, %rdi
  61 0066 E8000000              call    poll
  61      00
  62 006b 8945FC                movl    %eax, -4(%rbp)

[..]
  33:test.c        ****                 if (pfd[0].revents & POLLIN) {
  72                            .loc 1 33 0
  73 0092 0FB745E6              movzwl  -26(%rbp), %eax
  74 0096 98                    cwtl
  75 0097 83E001                andl    $1, %eax
  76 009a 84C0                  testb   %al, %al
  77 009c 743A                  je      .L2


and so on.

Thursday, July 28, 2011

OK GO goes HTML5

Check out the latest OK GO's absolutely fantastic video... done in...
HTML5. The interactive feature is great. (requires Google Chrome/Chromium).

allisnotlo.st

Tuesday, June 28, 2011

Thursday, June 16, 2011

Tuesday, June 14, 2011

Self-documenting code

trunk/Source/WebKit2/Platform/CoreIPC/Connection.h

enum MessageSendFlags {
    // Whether this message should be dispatched when waiting for a sync reply.
    // This is the default for synchronous messages.
    DispatchMessageEvenWhenWaitingForSyncReply = 1 << 0,
};


[..]

virtual Vector windowsToReceiveSentMessagesWhileWaitingForSyncReply() = 0;


[..]

void setOnlySendMessagesAsDispatchWhenWaitingForSyncReplyWhenProcessingSuchAMessage(bool);
void setShouldExitOnSyncMessageSendFailure(bool shouldExitOnSyncMessageSendFailure);


[..]

bool m_onlySendMessagesAsDispatchWhenWaitingForSyncReplyWhenProcessingSuchAMessage;
bool m_shouldExitOnSyncMessageSendFailure;
DidCloseOnConnectionWorkQueueCallback m_didCloseOnConnectionWorkQueueCallback;



and so on :-)



Thanks to Anatoly Vorobey for pointing.

Tuesday, June 7, 2011

GNU C Family Extensions

Some time ago I met confusing C ternary operator usage

return timeout ?: 1;


It turned out to be a GNU "Conditionals with Omitted Operands

C extension. The list of "Extensions to the C Language Family" can be found here.

This page is worth reading. For example, getting
the address of a label defined in the current function (or a containing
function) with the unary operator `&&'. The value has type void *. This value
is a constant and can be used wherever a constant of that type is valid.
For example:
     void *ptr;
     /* ... */
     ptr = &&foo;
To use these values, you need to be able to jump to one. This is done with
the computed goto statement, goto *exp;.
For example,
     goto *ptr;


Friday, May 27, 2011

gcc partial optimization

I missed that and so far thought this is hardly possible, but, for your note,
you can set per-function optimization levels with Function Specific Option Pragmas

For example:

#pragma GCC push_options
#pragma GCC optimize ("O2")
   code
#pragma GCC pop_options

OTOH, of course, you can split the source code into several files and compile
each with specific optimization options. Anyway.

Wednesday, May 11, 2011

signed to unsigned optimization

Consider the following code snippet:

#define MAX_NR 123

int
check_nr(int nr)
{
     return ((nr >= 0) && (nr < MAX_NR));
}



which is supposed to be compiled into the following instruction set:

   push   %rbp
   mov    %rsp,%rbp
   mov    %edi,-0x4(%rbp)
   cmpl   $0x0,-0x4(%rbp)
   js     0x4004be
   cmpl   $0x7a,-0x4(%rbp)
   jg     0x4004be
   mov    $0x1,%eax
   jmp    0x4004c3
   mov    $0x0,%eax
   pop    %rbp
   retq


The fun part begins when optimizer touches the code. Compiler can
prove that with the above limitation [0, MAX_NR) it's actually safe
to eliminate one of the checks by casting signed int nr to unsigned
int
nr, thus shortening the instruction set to:

   xor    %eax,%eax
   cmp    $0x7a,%edi
   setbe  %al
   retq


Future is awesome!

Saturday, May 7, 2011

KGPU

What is It?

KGPU is a GPU computing framework for the Linux kernel. It allows Linux kernel to call CUDA
programs running on GPUs directly. The motivation is to augment operating systems with GPUs
so that not only userspace applications but also the operating system itself can benefit from
GPU acceleration. It can also free the CPU from some computation intensive work by enabling
the GPU as an extra computing device.

[...]
The current KGPU release includes a demo of GPU augmentation: a GPU-accelerated AES cipher,

which can be used in conjunction with the eCryptfs encrypted filesystem. This enables read/write
bandwidths for an ecrypted filesystem that can reach a factor of 3x ~ 4x improvement over an
optimized CPU implementation (using a GTX 480 GPU).

See http://code.google.com/p/kgpu/ if interested.

Well, the next "big thing", I guess, would be calling kernel functions from the cloud ;-)

Monday, May 2, 2011

[PHORONIX] Linux Kernel Boot Statistics: 2.6.24 To 2.6.39

Phoronix guys tested linux kernel boot times through 2.6.24 to 2.6.39

Linux 2.6.24: 23 seconds / 17 MB/s
Linux 2.6.25: 21 seconds / 21 MB/s
Linux 2.6.26: 23 seconds / 21 MB/s
Linux 2.6.27: 24 seconds / 17 MB/s
Linux 2.6.28: 24 seconds / 18 MB/s
Linux 2.6.29: 25 seconds / 18 MB/s
Linux 2.6.30: 25 seconds / 19 MB/s
Linux 2.6.31: 25 seconds / 22 MB/s
Linux 2.6.32: 27 seconds / 21 MB/s
Linux 2.6.33: 28 seconds / 19 MB/s
Linux 2.6.34: 29 seconds / 21 MB/s
Linux 2.6.35: 30 seconds / 21 MB/s
Linux 2.6.36: 30 seconds / 22 MB/s
Linux 2.6.37: 29 seconds / 22 MB/s
Linux 2.6.38: 30 seconds / 22 MB/s
Linux 2.6.39: 39 seconds / 18 MB/s


Read full story here
Pretty correlates with my feeling -- on my laptop it's getting slower.

Though on 64-bit platform:
Linux 2.6.24: 26 seconds / 41 MB/s
Linux 2.6.25: 23 seconds / 35 MB/s
Linux 2.6.26: 26 seconds / 30 MB/s
Linux 2.6.27: 22 seconds / 32 MB/s
Linux 2.6.28: 26 seconds / 35 MB/s
Linux 2.6.29: 17 seconds / 32 MB/s
Linux 2.6.30: 25 seconds / 35 MB/s
Linux 2.6.31: 26 seconds / 32 MB/s
Linux 2.6.32: 26 seconds / 31 MB/s
Linux 2.6.33: 26 seconds / 34 MB/s
Linux 2.6.34: 19 seconds / 34 MB/s
Linux 2.6.35: 18 seconds / 34 MB/s
Linux 2.6.36: 18 seconds / 34 MB/s
Linux 2.6.37: 19 seconds / 34 MB/s

Sunday, April 17, 2011

Tuesday, April 5, 2011

mourning the loss of David Brownell

Greg KH wrote:
 As I have seen this tangentally mentioned already a few times
 publically, I figured it warranted it's own announcement now.

 Linux has lost a great developer with the passing of David Brownell
 recently and he will be greatly missed.



Sadly

Friday, March 25, 2011

[OOPS] elevator private data for REQ_FLUSH requests

Commit
    9d5a4e946ce5352f19400b6370f4cd8e72806278
    block: skip elevator data initialization for flush requests

    Skip elevator initialization for flush requests by passing priv=0 to
    blk_alloc_request() in get_request().  As such elv_set_request() is
    never called for flush requests.

introduced priv flag, to skip elevator_private data init for block FLUSH
requests. This lead to a NULL pointer deref on my machine in cfq_insert_request,
which requires elevator_private to be set:

  1 [   78.982169] Call Trace:
  2 [   78.982178]   cfq_insert_request+0x4e/0x47d
  3 [   78.982184]   ? do_raw_spin_lock+0x6b/0x122
  4 [   78.982189]   elv_insert+0x212/0x265
  5 [   78.982192]   __elv_add_request+0x50/0x52
  6 [   78.982195]   flush_plug_list+0xce/0x12f
  7 [   78.982199]   __blk_flush_plug+0x15/0x21
  8 [   78.982205]   schedule+0x43e/0xbea
  9 [   78.982211]   ? __lock_acquire+0x149d/0x1576
 10 [   78.982215]   ? drive_stat_acct+0x1b6/0x1c3
 11 [   78.982218]   ? drive_stat_acct+0x44/0x1c3
 12 [   78.982223]   ? __make_request+0x268/0x2bf
 13 [   78.982226]   schedule_timeout+0x35/0x3b8
 14 [   78.982230]   ? mark_held_locks+0x4b/0x6d
 15 [   78.982234]   ? _raw_spin_unlock_irq+0x28/0x56
 16 [   78.982239]   ? get_parent_ip+0xe/0x3e
 17 [   78.982244]   ? sub_preempt_count+0x90/0xa3
 18 [   78.982247]   wait_for_common+0xc3/0x141
 19 [   78.982251]   ? default_wake_function+0x0/0xf
 20 [   78.982254]   wait_for_completion+0x18/0x1a
 21 [   78.982258]   blkdev_issue_flush+0xcb/0x11a
 22 [   78.982264]   ext4_sync_file+0x2b3/0x302
 23 [   78.982268]   vfs_fsync_range+0x55/0x75
 24 [   78.982271]   generic_write_sync+0x3f/0x41
 25 [   78.982278]   generic_file_aio_write+0x8c/0xb9
 26 [   78.982281]   ext4_file_write+0x1dc/0x237
 27 [   78.982285]   ? do_raw_spin_lock+0x6b/0x122
 28 [   78.982288]   ? ext4_file_write+0x0/0x237
 29 [   78.982292]   do_sync_readv_writev+0xb4/0xf9
 30 [   78.982298]   ? security_file_permission+0x1e/0x84
 31 [   78.982302]   ? rw_verify_area+0xab/0xc8
 32 [   78.982305]   do_readv_writev+0xb8/0x17d
 33 [   78.982309]   ? fget_light+0x166/0x30b
 34 [   78.982312]   vfs_writev+0x40/0x42
 35 [   78.982315]   sys_pwritev+0x55/0x99
 36 [   78.982320]   system_call_fastpath+0x16/0x1b
 37

My solution was to use ELEVATOR_INSERT_FLUSH flag as an elv_insert param
for REQ_FLUSH | REQ_FUA requests (lkml)

---
 block/elevator.c |    2 ++
@@ -734,6 +734,8 @@ void __elv_add_request(struct request_queue *q, struct request *rq, int where)
    q->end_sector = rq_end_sector(rq);
    q->boundary_rq = rq;
   }
+ } else if (rq->cmd_flags & (REQ_FLUSH | REQ_FUA)) {
+  where = ELEVATOR_INSERT_FLUSH;
  } else if (!(rq->cmd_flags & REQ_ELVPRIV) &&
       where == ELEVATOR_INSERT_SORT)
   where = ELEVATOR_INSERT_BACK;



Jens Axboe has came up with more high-level solution:
 @@ -2702,7 +2702,10 @@ static void flush_plug_list(struct blk_plug *plug)
                /*
                 * rq is already accounted, so use raw insert
                 */
-               __elv_add_request(q, rq, ELEVATOR_INSERT_SORT_MERGE);
+               if (rq->cmd_flags & (REQ_FLUSH | REQ_FUA))
+                       __elv_add_request(q, rq, ELEVATOR_INSERT_FLUSH);
+               else
+                       __elv_add_request(q, rq, ELEVATOR_INSERT_SORT_MERGE);
        }

        if (q) {


(flush_plug_list is one level higher than __elv_add_request)

Git pull request message says (lkml)
"Thanks a lot to the people involved with fixing the first issue."

hope he was talking about me...


.

Thursday, March 24, 2011

g++ behind the static_cast

Assume that we have a simple C++ code

 const int i = static_cast<const int>(123.123f);

What is actually behind the static_cast?


The magic of static_cast starts in

tree
build_static_cast (tree type, tree expr, tsubst_flags_t complain)
{
  tree result;
  bool valid_p;

  if (type == error_mark_node || expr == error_mark_node)
    return error_mark_node;

  if (processing_template_decl)
    {
      expr = build_min (STATIC_CAST_EXPR, type, expr);
      /* We don't know if it will or will not have side effects.  */
      TREE_SIDE_EFFECTS (expr) = 1;
      return convert_from_reference (expr);
    }

  /* build_c_cast puts on a NOP_EXPR to make the result not an lvalue.
     Strip such NOP_EXPRs if VALUE is being used in non-lvalue context.  */
  if (TREE_CODE (type) != REFERENCE_TYPE
      && TREE_CODE (expr) == NOP_EXPR
      && TREE_TYPE (expr) == TREE_TYPE (TREE_OPERAND (expr, 0)))
    expr = TREE_OPERAND (expr, 0);

  result = build_static_cast_1 (type, expr, /*c_cast_p=*/false, &valid_p,
                                complain);
  if (valid_p)
    return result;

  if (complain & tf_error)
    error ("invalid static_cast from type %qT to type %qT",
           TREE_TYPE (expr), type);
  return error_mark_node;
}


There, for example, we can see g++'s "invalid static_cast ..." error message.

build_static_cast is a wrapper around build_static_cast_1, that, in turn,
is a big "switch", since it should deal with all kind of derived to
base casts, user defined casts, type instantiation, etc

static tree
build_static_cast_1 (tree type, tree expr, bool c_cast_p,
                     bool *valid_p, tsubst_flags_t complain)


For example:

   /* "An lvalue of type cv1 T1 can be cast to type rvalue reference to
      cv2 T2 if cv2 T2 is reference-compatible with cv1 T1 (8.5.3)."  */
   if (TREE_CODE (type) == REFERENCE_TYPE
       && TYPE_REF_IS_RVALUE (type)
       && real_lvalue_p (expr)
       && reference_related_p (TREE_TYPE (type), intype)
       && (c_cast_p || at_least_as_qualified_p (TREE_TYPE (type), intype)))
     {
       expr = build_typed_address (expr, type);
       return convert_from_reference (expr);
     }


From here we're getting to gcc/fold-const.c
Place where tons of interesting stuff are, for example, fold_convert_loc.
Which is, once again, a number of "switches" (convert from INTEGER to
CONST INTEGER
, etc.)
:

Convert expression ARG to type TYPE.  Used by the middle-end for
simple conversions in preference to calling the front-end's convert.

 fold_convert_loc (location_t loc, tree type, tree arg)
[..]
   switch (TREE_CODE (type))
     {
     case POINTER_TYPE:
     case REFERENCE_TYPE:
       /* Handle conversions between pointers to different address spaces.  */
       if (POINTER_TYPE_P (orig)
       && (TYPE_ADDR_SPACE (TREE_TYPE (type))
           != TYPE_ADDR_SPACE (TREE_TYPE (orig))))
     return fold_build1_loc (loc, ADDR_SPACE_CONVERT_EXPR, type, arg);

or
     case INTEGER_TYPE: case ENUMERAL_TYPE: case BOOLEAN_TYPE:
     case OFFSET_TYPE:
       if (TREE_CODE (arg) == INTEGER_CST)
     {
       tem = fold_convert_const (NOP_EXPR, type, arg);
       if (tem != NULL_TREE)
         return tem;
     }



Since we're requesting cast to const int -- the right function to call
is fold_convert_const, which is getting called from

 Fold a unary expression of code CODE and type TYPE with operand
 OP0.  Return the folded expression if folding is successful.
 Otherwise, return NULL_TREE.

 fold_unary_loc (location_t loc, enum tree_code code, tree type, tree op0)
[..]
   switch (code)
     {
     case PAREN_EXPR:
       /* Re-association barriers around constants and other re-association
      barriers can be removed.  */
       if (CONSTANT_CLASS_P (op0)
       || TREE_CODE (op0) == PAREN_EXPR)
     return fold_convert_loc (loc, type, op0);
       return NULL_TREE;


     CASE_CONVERT:
     case FLOAT_EXPR:
     case FIX_TRUNC_EXPR:
[..]
       tem = fold_convert_const (code, type, op0);
       return tem ? tem : NULL_TREE;



fold_convert_const decides what conversion exactly should be
performed (if any):

fold_convert_const (enum tree_code code, tree type, tree arg1)
[..]
   if (POINTER_TYPE_P (type) || INTEGRAL_TYPE_P (type)
       || TREE_CODE (type) == OFFSET_TYPE)
     {
       if (TREE_CODE (arg1) == INTEGER_CST)
     return fold_convert_const_int_from_int (type, arg1);
       else if (TREE_CODE (arg1) == REAL_CST)
     return fold_convert_const_int_from_real (code, type, arg1);
       else if (TREE_CODE (arg1) == FIXED_CST)
     return fold_convert_const_int_from_fixed (type, arg1);
     }
[..]


which is finally getting closer to a cast itself by

real_to_integer2 (HOST_WIDE_INT *plow, HOST_WIDE_INT *phigh,
                  const REAL_VALUE_TYPE *r)


call in gcc/real.c

   The floating point model used internally is not exactly IEEE 754
   compliant, and close to the description in the ISO C99 standard,
   section 5.2.4.2.2 Characteristics of floating types.

   Specifically

        x = s * b^e * \sum_{k=1}^p f_k * b^{-k}

        where
                s = sign (+- 1)
                b = base or radix, here always 2
                e = exponent
                p = precision (the number of base-b digits in the significand)
                f_k = the digits of the significand.

   We differ from typical IEEE 754 encodings in that the entire
   significand is fractional.  Normalized significands are in the
   range [0.5, 1.0).

   A requirement of the model is that P be larger than the largest
   supported target floating-point type by at least 2 bits.  This gives
   us proper rounding when we truncate to the target type.  In addition,
   E must be large enough to hold the smallest supported denormal number
   in a normalized form.

   Both of these requirements are easily satisfied.  The largest target
   significand is 113 bits; we store at least 160.  The smallest
   denormal number fits in 17 exponent bits; we store 26.

   Note that the decimal string conversion routines are sensitive to
   rounding errors.  Since the raw arithmetic routines do not themselves
   have guard digits or rounding, the computation of 10**exp can
   accumulate more than a few digits of error.  The previous incarnation
   of real.c successfully used a 144-bit fraction; given the current
   layout of REAL_VALUE_TYPE we're forced to expand to at least 160 bits.




There is a bunch of fold_convert_* functions, e.g.:
fold_convert_const_int_from_int
fold_convert_const_int_from_real
fold_convert_const_int_from_fixed
fold_convert_const_real_from_real


and so on.

Wednesday, March 23, 2011

kvm: x86 instruction decoder/emulator

In case you've been wondered about kvm emulation, devs did
steb-by-step decoding/emulation. Really outstanding and impressive:

arch/x86/kvm/emulate.c
x86_emulate_insn
[..]
3036     switch (c->b) {
[..]
3078     case 0x28 ... 0x2d:
3079           sub:      /* sub */
3080         emulate_2op_SrcV("sub", c->src, c->dst, ctxt->eflags);
3081         break;
3082     case 0x30 ... 0x35:
3083           xor:      /* xor */
3084         emulate_2op_SrcV("xor", c->src, c->dst, ctxt->eflags);
3085         break;
3086     case 0x38 ... 0x3d:
3087           cmp:      /* cmp */
3088         emulate_2op_SrcV("cmp", c->src, c->dst, ctxt->eflags);
3089         break;
3090     case 0x40 ... 0x47: /* inc r16/r32 */
3091         emulate_1op("inc", c->dst, ctxt->eflags);
3092         break;
3093     case 0x48 ... 0x4f: /* dec r16/r32 */
3094         emulate_1op("dec", c->dst, ctxt->eflags);
3095         break;
3096     case 0x58 ... 0x5f: /* pop reg */
3097     pop_instruction:
3098         rc = emulate_pop(ctxt, ops, &c->dst.val, c->op_bytes);
3099         break;
3100     case 0x60/* pusha */
3101         rc = emulate_pusha(ctxt, ops);
3102         break;
3103     case 0x61/* popa */
3104         rc = emulate_popa(ctxt, ops);
3105         break;
3106     case 0x63:      /* movsxd */
3107         if (ctxt->mode != X86EMUL_MODE_PROT64)
3108             goto cannot_emulate;
3109         c->dst.val = (s32) c->src.val;
3110         break;
3111     case 0x6c:      /* insb */
3112     case 0x6d:      /* insw/insd */
3113         c->src.val = c->regs[VCPU_REGS_RDX];
3114         goto do_io_in;
3115     case 0x6e:      /* outsb */
3116     case 0x6f:      /* outsw/outsd */
3117         c->dst.val = c->regs[VCPU_REGS_RDX];
3118         goto do_io_out;
3119         break;
3120     case 0x70 ... 0x7f: /* jcc (short) */
3121         if (test_cc(c->b, ctxt->eflags))
3122             jmp_rel(c, c->src.val);
3123         break;
3124     case 0x80 ... 0x83: /* Grp1 */
3125         switch (c->modrm_reg) {
3126         case 0:
3127             goto add;
3128         case 1:
3129             goto or;
3130         case 2:
3131             goto adc;
3132         case 3:
3133             goto sbb;
3134         case 4:
3135             goto and;
3136         case 5:
3137             goto sub;
3138         case 6:
3139             goto xor;
3140         case 7:
3141             goto cmp;
3142         }
3143         break;
3144     case 0x84 ... 0x85:
[..]



the whole platform... with sysenter/sysexit/syscal/etc.

emulate_sysenter
[..]
1650     /* inject #GP if in real mode */
1651     if (ctxt->mode == X86EMUL_MODE_REAL)
1652         return emulate_gp(ctxt, 0);
1653
1654     /* XXX sysenter/sysexit have not been tested in 64bit mode.
1655     * Therefore, we inject an #UD.
1656     */
1657     if (ctxt->mode == X86EMUL_MODE_PROT64)
1658         return emulate_ud(ctxt);
1659
1660     setup_syscalls_segments(ctxt, ops, &cs, &ss);
1661
1662     ops->get_msr(ctxt->vcpu, MSR_IA32_SYSENTER_CS, &msr_data);
1663     switch (ctxt->mode) {
1664     case X86EMUL_MODE_PROT32:
1665         if ((msr_data & 0xfffc) == 0x0)
1666             return emulate_gp(ctxt, 0);
1667         break;
1668     case X86EMUL_MODE_PROT64:
1669         if (msr_data == 0x0)
1670             return emulate_gp(ctxt, 0);
1671         break;
1672     }
[..]

Monday, March 21, 2011

gcc-4.6 RC1

rev 171232
make -j8 -k check

libstdc++-v3/testsuite/libstdc++.sum
=== libstdc++ Summary ===

# of expected passes 7674
# of unexpected failures 16
# of expected failures 83
# of unresolved testcases 1
# of unsupported tests 392


gcc/testsuite/g++/g++.sum
=== g++ Summary ===

# of expected passes 27262
# of expected failures 161
# of unsupported tests 359
gcc/testsuite/g++/../../g++ version 4.6.0 20110320 (prerelease) (GCC)


gcc/testsuite/gcc/gcc.sum
=== gcc Summary ===

# of expected passes 78155
# of unexpected failures 31
# of unexpected successes 34
# of expected failures 230
# of unsupported tests 1087
gcc/xgcc version 4.6.0 20110320 (prerelease) (GCC)

Tuesday, March 1, 2011

llvm: sizeof for `primitive' types

If you ever wondered how does llvm calculates sizeof for
`primitive' types (I did), target independent types are hard-coded:

include/llvm/CodeGen/ValueTypes.h

  /// MVT - Machine Value Type.  Every type that is supported natively by some
  /// processor targeted by LLVM occurs here.  This means that any legal value
  /// type can be represented by a MVT.
  class MVT {
  public:
    enum SimpleValueType {
      // If you change this numbering, you must change the values in
      // ValueTypes.td as well!
      Other          =   0,   // This is a non-standard value
      i1             =   1,   // This is a 1 bit integer value
      i8             =   2,   // This is an 8 bit integer value
      i16            =   3,   // This is a 16 bit integer value
      i32            =   4,   // This is a 32 bit integer value
      i64            =   5,   // This is a 64 bit integer value
      i128           =   6,   // This is a 128 bit integer value
[..]

And here we go:
    unsigned getSizeInBits() const {
      switch (SimpleTy) {
      case iPTR:
        assert(0 && "Value type size is target-dependent. Ask TLI.");
      case iPTRAny:
      case iAny:
      case fAny:
        assert(0 && "Value type is overloaded.");
      default:
        assert(0 && "getSizeInBits called on extended MVT.");
      case i1  :  return 1;
      case i8  :  return 8;
      case i16 :
      case v2i8:  return 16;
      case f32 :
      case i32 :
      case v4i8:
      case v2i16: return 32;
      case x86mmx:
      case f64 :
      case i64 :
      case v8i8:
      case v4i16:
      case v2i32:
      case v1i64:
      case v2f32: return 64;
      case f80 :  return 80;
      case f128:
      case ppcf128:
      case i128:
      case v16i8:
      case v8i16:
      case v4i32:
      case v2i64:
      case v4f32:
      case v2f64: return 128;
      case v32i8:
      case v16i16:
      case v8i32:
      case v4i64:
      case v8f32:
      case v4f64: return 256;
      case v8i64: return 512;
      }
    }


`Primitive' target dependent types:
lib/VMCore/Type.cpp
unsigned Type::getPrimitiveSizeInBits() const {
  switch (getTypeID()) {
  case Type::FloatTyID: return 32;
  case Type::DoubleTyID: return 64;
  case Type::X86_FP80TyID: return 80;
  case Type::FP128TyID: return 128;
  case Type::PPC_FP128TyID: return 128;
  case Type::X86_MMXTyID: return 64;
  case Type::IntegerTyID: return cast(this)->getBitWidth();
  case Type::VectorTyID:  return cast(this)->getBitWidth();
  default: return 0;
  }
}

[..]

int Type::getFPMantissaWidth() const {
  if (const VectorType *VTy = dyn_cast(this))
    return VTy->getElementType()->getFPMantissaWidth();
  assert(isFloatingPointTy() && "Not a floating point type!");
  if (ID == FloatTyID) return 24;
  if (ID == DoubleTyID) return 53;
  if (ID == X86_FP80TyID) return 64;
  if (ID == FP128TyID) return 113;
  assert(ID == PPC_FP128TyID && "unknown fp type");
  return -1;
}


Target dependent types:

lib/Target/ARM/ARMAsmBackend.cpp


unsigned getPointerSize() const { return 4; }

lib/VMCore/Module.cpp
/// Target Pointer Size information...
Module::PointerSize Module::getPointerSize() const {
  StringRef temp = DataLayout;
  Module::PointerSize ret = AnyPointerSize;

  while (!temp.empty()) {
    StringRef token, signalToken;
    tie(token, temp) = getToken(temp, "-");
    tie(signalToken, token) = getToken(token, ":");

    if (signalToken[0] == 'p') {
      int size = 0;
      getToken(token, ":").first.getAsInteger(10, size);
      if (size == 32)
        ret = Pointer32;
      else if (size == 64)
        ret = Pointer64;
    }
  }

  return ret;
}



Where
lib/Support/StringRef.cpp

/// GetAsUnsignedInteger - Workhorse method that converts a integer character
/// sequence of radix up to 36 to an unsigned long long value.
static bool GetAsUnsignedInteger(StringRef Str, unsigned Radix,
                                 unsigned long long &Result) {
  // Autosense radix if not specified.
  if (Radix == 0)
    Radix = GetAutoSenseRadix(Str);

  // Empty strings (after the radix autosense) are invalid.
  if (Str.empty()) return true;

  // Parse all the bytes of the string given this radix.  Watch for overflow.
  Result = 0;
  while (!Str.empty()) {
    unsigned CharVal;
    if (Str[0] >= '0' && Str[0] <= '9')
      CharVal = Str[0]-'0';
    else if (Str[0] >= 'a' && Str[0] <= 'z')
      CharVal = Str[0]-'a'+10;
    else if (Str[0] >= 'A' && Str[0] <= 'Z')
      CharVal = Str[0]-'A'+10;
    else
      return true;

    // If the parsed value is larger than the integer radix, the string is
    // invalid.
    if (CharVal >= Radix)
      return true;

    // Add in this character.
    unsigned long long PrevResult = Result;
    Result = Result*Radix+CharVal;

    // Check for overflow.
    if (Result < PrevResult)
      return true;

    Str = Str.substr(1);
  }

  return false;
}
(same is for GetAsUnsignedInteger)


I should say -- it's a pleasure to read llvm source code.
